Megh Neel - 150W BLDC Motor
HIGHLIGHTS |
- 150W-250Watts (Input), 3000 RPM Brushless DC Motor
- In-runner rotor
- Operating temperature up to 80oC
- External Control with Sensor / sensor-less commutation
- Made in Coimbatore, India
- Typical applications include:- Bio centrifugal units, Micro AGV, Fish Feeders, Pumps etc.,
|
![](/portals/0/IMG_20230214_100405.jpg?ver=s9tVEh5_tDBwX2LWdTNv-g%3d%3d) |
SPECIFICATIONS |
Parameter |
Value |
Rated Voltage |
24VDC |
230VAC |
Rated Current |
12 A |
1.15 A |
Rated Power (Input) |
250 Watts (Max) |
Rated Speed (RPM) |
3000 RPM |
Rated Torque (Nm) |
0.67 Nm |
Motor Mounting |
Face Mounting |
Shaft Diameter |
11 mm / 12 mm / 19 mm diameter |
Shaft Length |
20 mm length |
Finish |
Powder Coated |
Dimensions |
![](/portals/0/MEGHNEEL-IR120-BLDC-100W-DRAWING-V01.jpg?ver=4Ys_wiRjgvnAGlXatFArYA%3d%3d) |
Download detailed technical specifications here
|
